Art. no. 27106400
Offering our customers the highest quality at all times is a fundamental part of the Hansgrohe company philosophy.
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.
| Item no. | DescriptionArticle no. |
|---|
| 1 | shower arm92680000 |
| 2 | O-ring 9x1,598117000 |
| 3 | head shower92681000 |
| 4 | cover93392000 |
| 5 | cartridge, assy93389000 |
| 6 | spray insert92923000 |
| 7 | frame93391000 |
| 8 | spray body92704000 |
| 9 | filter92683000 |
| 10 | O-ring 24x298388000 |
| 11 | aerator laminar92684000 |
| 12 | O-ring 15x298163000 |
| 13 | special tool92686000 |
| 14 | tile-matching-disk92679000 |
| 15 | pipe with cover (950 mm)92678000 |
| 16 | pipe with cover (850 mm)93409000 |
| 17 | shelf92677000 |
| 18 | Shower Set26721400 |
| 19 | handshower26530400 |
| 20 | filter insert97708000 |
| 21 | shower holder28331000 |
| 22 | mounting set40915000 |
| 23 | shower hose Isiflex'B 1,60 m28276000 |
| 24 | seal98058000 |
| 25 | handle for thermostat92673000 |
| 26 | safety set92675000 |
| 27 | handle fixing set92136000 |
| 28 | thermostat cartridge96633000 |
| 29 | set of symbols98367000 |
| 30 | O-ring 20x198140000 |
| 31 | shut off unit95758000 |
| 32 | nut98368000 |
| 33 | O-ring 22x1,598173000 |
| 34 | O-ring 14x298129000 |
| 35 | non return valve97980000 |
| 36 | hose connection angel25948000 |
| 37 | O-ring 17x2,598387000 |
| 38 | set of non return valves DW 1597350000 |
| 39 | filter97973000 |
| 40 | connection hose 650 mm G1/292676000 |
| 41 | O-ring 11x298127000 |
