MySelect S Showerpipe 240 1jet with thermostat
Art. no. 26758400
Please try again.
Please try again.
Innovative technologies
More pleasure, more efficiency
Products with this shower technology combined water with air to pamper you with more voluminous, lighter and softer water droplets on your skin. For greater showering pleasure with water efficiency.Learn more
Fast anti-limescale function
Who really likes cleaning? Our invention, QuickClean, rapidly removes dirt and limescale deposits from mixers and showers. Flexible silicon nubs make sure of this. Beware of copies: this QuickClean logo is the only guarantee of genuine Hansgrohe quality.Learn more
Great showering pleasure
You really need to experience this: great showering pleasure with jet types that has a feel-good factor. hansgrohe's hand and overhead showers, with a diameter of between 100 and 600 mm, envelop you in a real water dream – and ensure XXLPerformance in your bathroom.Learn more
Intuitive jet adjustment
Soft water droplets or an invigorating massage? Select the jet type you want in just one click, for even more showering fun.Learn more
Five-year manufacturer's guarantee
Offering our customers the highest quality at all times is a fundamental part of the Hansgrohe company philosophy.
Similar products
Article features
- consists of: overhead shower, hand shower, shower thermostat, shower hose, slider
- shower head size: 240 mm
- overhead shower angle adjustable
- spray type: RainAir
- flow rate RainAir spray (at 0.3 MPa): 12 l/min
- shower arm length: 380 mm
- swivel shower arm
- thermostat Versostat
- safety lock at 40° C
- adjustable hot water limitation
- outlets controlled via turning handle
- installation type: exposed installation
- connection dimension DN15
- connection thread G ½
- centre distance 150 ± 12 mm
- suitable for continuous flow water heaters with an output of 18 kW
Installation information
Information
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.
Scope of supply
- Showerpipe with thermostat
- escutcheons
- S-connections
- mounting material
- assembly instruction
Spare parts for build year 05/15
View older models in the spare parts catalogueItem no. | DescriptionArticle no. |
---|
a | set of S-unions (±32 mm)98592000 |
1 | pipe 1070 mm92444000 |
2 | lock washer98942000 |
3 | hollow set screw M4x697767000 |
4 | filter packing94246000 |
5 | nut97958000 |
6 | ball joint97331000 |
7 | lever collar97536000 |
8 | ball joint97552000 |
9 | seal97606000 |
10 | head shower Ø 240 mm98855000 |
11 | air jet95794000 |
12 | wall support95365000 |
13 | mounting set96179000 |
14 | tile-matching-disk95163000 |
15 | wall support95406000 |
16 | O-ring 15x298163000 |
17 | cover92520000 |
18 | support, assy92366000 |
19 | O-ring 15x2,598131000 |
20 | O-ring 12x2,2598382000 |
21 | handshower26636400 |
22 | filter insert97708000 |
23 | shower hose Isiflex'B 1,60 m28276000 |
24 | seal98058000 |
25 | O-ring 14x298129000 |
26 | Thermostat92555000 |
27 | handle92200000 |
28 | handle fixing set95843000 |
29 | safety set92199000 |
30 | nut98913000 |
31 | O-ring 26x1,598390000 |
32 | thermostat cartridge98282000 |
33 | cartridge for exchanged connections92373000 |
34 | stop ring for flow control95927000 |
35 | shut off unit with selector98283000 |
36 | set of nuts96157000 |
37 | non return valve (pressure-resistant up to 2 MPa)93136000 |
38 | non return valve96737000 |
39 | filter packing96922000 |
40 | escutcheon Ø 68 mm96467000 |
41 | noise reduction96429000 |
42 | set of S-unions (±12 mm)94140000 |
