Art. no. 32532670
Products with this shower technology combined water with air to pamper you with more voluminous, lighter and softer water droplets on your skin. For greater showering pleasure with water efficiency.Learn more
Who really likes cleaning? Our invention, QuickClean, rapidly removes dirt and limescale deposits from mixers and showers. Flexible silicon nubs make sure of this. Beware of copies: this QuickClean logo is the only guarantee of genuine Hansgrohe quality.Learn more
Offering our customers the highest quality at all times is a fundamental part of the Hansgrohe company philosophy.
BIM data
Technical data
Item no. | DescriptionArticle no. |
---|
a | concealed item10452180 |
1 | handle93075670 |
2 | screw cover96338000 |
3 | flange97406670 |
4 | nut97209000 |
5 | O-Ring 32x298193000 |
6 | cartridge, assy92730000 |
7 | locking screw for handle95140000 |
8 | seal95008000 |
9 | O-ring 35x292604000 |
10 | aerator M24x1 (30 l/min)96512670 |
11 | diverter knob95284670 |
12 | sleeve97979670 |
13 | selector97978000 |
14 | non return valve97980000 |
15 | seal98058000 |
16 | shower hose 1,25 m28282670 |
17 | shower holder, assy96295670 |
18 | handshower28532XXX |
19 | filter packing94246000 |
20 | escutcheon93245670 |
21 | O-ring 9x1,598117000 |
22 | hexagon socket screw M10x3597670000 |
23 | O-ring 44x2,598162000 |
24 | O-ring 29x398371000 |
25 | O-ring 7x298419000 |
26 | extension set 60 mm97686000 |
