Art. no. 32572000
Offering our customers the highest quality at all times is a fundamental part of the Hansgrohe company philosophy.
| Item no. | DescriptionArticle no. |
|---|
| b | fixation extension 35 mm13898000 |
| a | push-open waste set50100000 |
| 1 | handle93070000 |
| 2 | adapter for handle92526000 |
| 3 | nut92528000 |
| 4 | O-ring 27x1,592527000 |
| 5 | cartridge, assy92529000 |
| 6 | adapter for cartridge98866000 |
| 7 | O-ring 23x298398000 |
| 8 | aerator M24x1 (5 l/min)92996000 |
| 9 | service tool95661000 |
| 10 | escutcheon93048000 |
| 11 | flat seal98749000 |
| 12 | fixing set (Ø 32)13961000 |
| 13 | lever collar97548000 |
| 14 | connection hose 600 mm M8x0,75 G3/892629000 |
| 15 | O-ring 7x1,598422000 |
| 16 | non return valve DW 1096456000 |
| 17 | filter92532000 |
| 18 | sealing set92533000 |
