Art. no. 13114000
Offering our customers the highest quality at all times is a fundamental part of the Hansgrohe company philosophy.
| Item no. | DescriptionArticle no. |
|---|
| b | brake disc92469000 |
| a | set of S-unions (±32 mm)98592000 |
| 1 | handle95836000 |
| 2 | pushbutton92848000 |
| 3 | handle fixing set95843000 |
| 4 | safety set95839000 |
| 5 | nut98913000 |
| 6 | O-ring 26x1,598390000 |
| 7 | thermostat cartridge98282000 |
| 8 | cartridge for exchanged connections92373000 |
| 9 | aerator M24x1 (30 l/min)96512000 |
| 10 | connecting thread95392000 |
| 11 | O-ring 14x298129000 |
| 12 | safety set95840000 |
| 13 | shut off unit with selector98283000 |
| 14 | set of nuts96157000 |
| 15 | non return valve (pressure-resistant up to 2 MPa)93136000 |
| 16 | non return valve96737000 |
| 17 | O-ring 17x1,598137000 |
| 18 | filter packing96922000 |
| 19 | escutcheon Ø 68 mm96467000 |
| 20 | noise reduction96429000 |
| 21 | set of S-unions (±12 mm)94140000 |
