Art. no. 27223000
Offering our customers the highest quality at all times is a fundamental part of the Hansgrohe company philosophy.
Please always observe the safety and installation information for your product. You find these details within the assembly instructions.
| Item no. | DescriptionArticle no. |
|---|
| c | non return valve95699000 |
| a | set of S-unions (±32 mm)98592000 |
| b | brake disc92469000 |
| 1 | mounting set98716000 |
| 2 | wall flange95688000 |
| 3 | O-Ring 50x298187000 |
| 4 | tile-matching-disk95239000 |
| 5 | escutcheon Ø 60 mm95692000 |
| 6 | O-ring 20x298165000 |
| 7 | screw92137000 |
| 8 | hollow set screw M6x598447000 |
| 9 | sleeve92166000 |
| 10 | shower arm95985000 |
| 11 | head shower26464000 |
| 12 | filter packing96477000 |
| 13 | ball joint98941000 |
| 14 | lock washer98942000 |
| 15 | lever collar97536000 |
| 16 | seal97606000 |
| 17 | air jet95794000 |
| 18 | O-ring 7x298419000 |
| 19 | O-ring 15x2,598131000 |
| 20 | support, assy97651000 |
| 21 | pipe 1400 mm95983000 |
| 22 | O-ring 12x2,2598382000 |
| 23 | handshower28535000 |
| 24 | filter insert97708000 |
| 25 | shower hose Isiflex'B 1,60 m28276000 |
| 26 | handle95836000 |
| 27 | pushbutton92848000 |
| 28 | handle fixing set95843000 |
| 29 | safety set95839000 |
| 30 | nut98913000 |
| 31 | O-ring 26x1,598390000 |
| 32 | thermostat cartridge98282000 |
| 33 | cartridge for exchanged connections92373000 |
| 34 | aerator M24x1 (30 l/min)96512000 |
| 35 | diverter knob96466000 |
| 36 | sleeve97738000 |
| 37 | selector assy94077000 |
| 38 | seal98058000 |
| 39 | shut off unit with selector98283000 |
| 40 | safety set95984000 |
| 41 | set of nuts96157000 |
| 42 | O-ring 17x1,598137000 |
| 43 | escutcheon Ø 68 mm96467000 |
| 44 | noise reduction96429000 |
| 45 | set of S-unions (±12 mm)94140000 |
